AISI 430 Stainless Steel Bar is a ferritic stainless steel grade known for its excellent corrosion resistance and formability. It's primarily used in applications where the aesthetic appearance is crucial, and moderate corrosion resistance suffices without the need for the higher cost associated with austenitic grades like 304.
Composition:
The typical chemical composition of 430 Stainless Steel includes:
- Chromium (Cr): Around 16% to 18%, which provides basic corrosion resistance.
- Carbon (C): Typically low (<0.15%), reducing the risk of intergranular corrosion.
- Manganese (Mn), Silicon (Si), and Phosphorus (P) are present in small amounts to improve strength and formability.
- Nickel (Ni) content is very low or non-existent, making it less expensive compared to nickel-bearing austenitic stainless steels.
- Sulfur (S) and other elements may also be present in trace quantities.
Characteristics:
1. Corrosion Resistance: Offers good corrosion resistance against atmospheric corrosion, water, and some chemicals, especially when polished.
2. Aesthetic Appeal: Due to its ability to retain a smooth, shiny finish after polishing, it's popular for decorative purposes.
3. Formability: Exhibits excellent cold forming properties and can be easily shaped into bars and various components.
4. Heat Resistance: Has fair heat resistance but is not as suitable for high-temperature applications as some other stainless steel grades.
5. Non-Magnetic Properties: Ferritic steels like 430 are generally non-magnetic in the annealed condition, although they can become slightly magnetic after severe cold working.
Use:
1. Kitchen Appliances: For manufacturing kitchenware such as cookware, dishwashers, refrigerators, and oven components due to its attractive appearance and corrosion resistance.
2. Architectural Applications: Used in architectural trim, railings, and facades because of its durability and aesthetic appeal.
3. Automotive Industry: Components such as trims, exhaust systems, and decorative parts benefit from its corrosion resistance and formability.
4. Furniture and Fixtures: In furniture design and bathroom fixtures due to its aesthetic qualities and corrosion resistance.
5. Miscellaneous Applications: Also found in chemical processing equipment, storage tanks, and general-purpose applications that do not require the high corrosion resistance of austenitic grades.
In summary, AISI 430 Stainless Steel Bar is an economical and versatile material well-suited for applications where moderate corrosion resistance and aesthetic appearance are essential. Its ferritic structure and lower cost make it a popular choice across several industries, particularly where forming and shaping are critical aspects of the fabrication process.
| Product Name | 430 Stainless Steel Bar |
| Technique | Cold Rolled; Hot Rolled |
| Shape | Round, Square, Hexagonal |
| Material | 200 series,300 series,400 series,900 series |
| 201,202,304,304L,316,316L,321,310S,403,410,416,420,430,940L. etc | |
| Standard | JIS/SUS/GB/DIN/ASTM/AISI/EN |
| Surface | BA, 2B, 2D, 4K, 6K, 8K, NO.4, HL, SB, Embossed |
| Package | clients' requirement and Standard export sea-worthy packing |
| MOQ | 1 ton |
Available Size Range
| Dimension | Range |
| Diameter | 3-480mm |
| Length | 1m-12m or as required |
Chemical Properties of Frequently-used :
| UNS | ASTM | EN | JIS | C% | Mn% | P% | S% | Si% | Cr% | Ni% | Mo% |
| S20100 | 201 | 1.4372 | SUS201 | ≤0.15 | 5.5-7.5 | ≤0.06 | ≤0.03 | ≤1.00 | 16.0-18.0 | 3.5-5.5 | - |
| S20200 | 202 | 1.4373 | SUS202 | ≤0.15 | 7.5-10.0 | ≤0.06 | ≤0.03 | ≤1.00 | 17.0-19.0 | 4.0-6.0 | - |
| S30100 | 301 | 1.4319 | SUS301 | ≤0.15 | ≤2.00 | ≤0.045 | ≤0.03 | ≤1.00 | 16.0-18.0 | 6.0-8.0 | - |
| S30400 | 304 | 1.4301 | SUS304 | ≤0.08 | ≤2.00 | ≤0.045 | ≤0.03 | ≤0.75 | 18.0-20.0 | 8.0-10.5 | - |
| S30403 | 304L | 1.4306 | SUS304L | ≤0.03 | ≤2.00 | ≤0.045 | ≤0.03 | ≤0.75 | 18.0-20.0 | 8.0-12.0 | - |
| S30908 | 309S | 1.4833 | SUS309S | ≤0.08 | ≤2.00 | ≤0.045 | ≤0.03 | ≤0.75 | 22.0-24.0 | 12.0-15.0 | - |
| S31008 | 310S | 1.4845 | SUS310S | ≤0.08 | ≤2.00 | ≤0.045 | ≤0.03 | ≤1.50 | 24.0-26.0 | 19.0-22.0 | - |
| S31600 | 316 | 1.4401 | SUS316 | ≤0.08 | ≤2.00 | ≤0.045 | ≤0.03 | ≤0.75 | 16.0-18.0 | 10.0-14.0 | 2.0-3.0 |
| S31603 | 316L | 1.4404 | SUS316L | ≤0.03 | ≤2.00 | ≤0.045 | ≤0.03 | ≤0.75 | 16.0-18.0 | 10.0-14.0 | 2.0-3.0 |
| S31703 | 317L | 1.4438 | SUS317L | ≤0.03 | ≤2.00 | ≤0.045 | ≤0.03 | ≤0.75 | 18.0-20.0 | 11.0-15.0 | 3.0-4.0 |
| S32100 | 321 | 1.4541 | SUS321 | ≤0.08 | ≤2.00 | ≤0.045 | ≤0.03 | ≤0.75 | 17.0-19.0 | 9.0-12.0 | - |
| S34700 | 347 | 1.455 | SUS347 | ≤0.08 | ≤2.00 | ≤0.045 | ≤0.03 | ≤0.75 | 17.0-19.0 | 9.0-13.0 | - |
| S40500 | 405 | 1.4002 | SUS405 | ≤0.08 | ≤1.00 | ≤0.04 | ≤0.03 | ≤1.00 | 11.5-14.5 | ≤0.60 | - |
| S40900 | 409 | 1.4512 | SUS409 | ≤0.08 | ≤1.00 | ≤0.045 | ≤0.03 | ≤1.00 | 10.5-11.75 | ≤0.50 | - |
| S43000 | 430 | 1.4016 | SUS430 | ≤0.12 | ≤1.00 | ≤0.040 | ≤0.03 | ≤0.75 | 16.0-18.0 | ≤0.60 | - |
| S43400 | 434 | 1.4113 | SUS434 | ≤0.12 | ≤1.00 | ≤0.040 | ≤0.03 | ≤1.00 | 16.0-18.0 | - | - |
| S44400 | 444 | 1.4521 | SUS444L | ≤0.025 | ≤1.00 | ≤0.045 | ≤0.03 | ≤1.00 | 17.5-19.5 | ≤1.00 | - |
| S40300 | 403 | - | SUS403 | ≤0.15 | 5.5-7.5 | ≤0.04 | ≤0.03 | ≤0.50 | 11.5-13.0 | ≤0.60 | - |
| S410000 | 410 | 1.40006 | SUS410 | ≤0.15 | ≤1.00 | ≤0.035 | ≤0.03 | ≤1.00 | 11.5-13.5 | ≤0.60 | ≤1.00 |
| S42000 | 420 | 1.4021 | SUS420J1 | 0.16~0.25 | ≤1.00 | ≤0.04 | ≤0.03 | ≤1.00 | 12.0-14.0 | ≤0.75 | ≤1.00 |
| S440A | 440A | 1.4028 | SUS440A | 0.60~0.75 | ≤1.00 | ≤0.04 | ≤0.03 | ≤1.00 | 16.0-18.0 | - | ≤0.75 |
| S32750 | SAD2507 | 1.441 | ≤0.03 | ≤1.2 | ≤0.035 | ≤0.02 | ≤0.80 | 24.0-26.0 | 6.0-8.0 | 3.0-5.0 | |
| S31803 | SAF2205 | 1.4462 | ≤0.03 | ≤2.0 | ≤0.03 | ≤0.02 | ≤1.00 | 21.0-23.0 | 4.0-6.5 | 2.5-3.5 | |
| N08904 | 904L | 1.4539 | ≤0.0.3 | ≤2.0 | ≤0.035 | ≤0.03 | ≤1.00 | 18.0-20.0 | 23.0-25.0 | 3.0-4.0 |
Stainless Steel Material Properties:
| Type No. | Tensile Strength, ksi | Yield Strength, ksi | Elongation in 2 inches, % | Reduction of Area, % | Brinell Hardness |
| 301 | 110 | 40 | 60 | 70 | 165 |
| 302 | 90 | 40 | 55 | 70 | 150 |
| 303 | 90 | 35 | 50 | 55 | 160 |
| 304 | 85 | 35 | 55 | 70 | 150 |
| 304L | 80 | 30 | 55 | 70 | 140 |
| 316 | 85 | 35 | 60 | 70 | 150 |
| 316L | 78 | 30 | 55 | 65 | 145 |
| 321 | 85 | 35 | 55 | 65 | 150 |
| 410 | 75 | 40 | 35 | 70 | 155 |
| 416 | 75 | 40 | 30 | 65 | 155 |
| 420 | 95 | 50 | 25 | - | 241 |
| 430F | 80 | 45 | 25 | 50 | 165 |
| 15-5 | 160 | 145 | 15 | - | 330 |
| 17-4 (Condition A) | 150 | 110 | 10 | 45 | 332 |
